AlgoLaser DIY Kit Laser Engraver 2W/5W/10W Output Diode Cutting Machine High Precision Engraving Machines DIY Cutter for Wood
AlgoLaser DIY Kit Laser Engraver 2W/5W/10W Output Diode Cutting Machine High Precision Engraving Machines DIY Cutter for Wood
40 in stock
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: Ortur
Certification: ce
Certification: CE
Model Number: Laser Cutting Air Assist Pump
Product Name: AlgoLaser DIY Kit
Laser Power: 2W/5W/10W/20W
Engraving Area: 400x400mm
Speed: 0-12000mm/min
Control Software: LaserGRBL (free), LightBurn (Paid Software), Wifi APP
Description:
Ortur Founder Mr. Justin Tan created one new brand "Algolaser" with Ortur original R&D team, production team, marketing and sale team. We dedicated to providing intelligent high-power handworking tools fo DIY enthusiasts, small manufacturing enterprises, retail store owners, workrooms, artists, engineers and self-employed people! Choose Algolaser, your lifelong business partner!
Feature:
Motherboard:ALGOLASER_DIY_KIT_V1.2
Engraving area: 400*400mm
With Expand kits Engraving area :400*800mm(need to order separately)
Control Software:LaserGRBL (free), LightBurn (Paid Software), Wifi APP
Safety Precautions:
Machine Offset Detection and Protection
Machine Tilt Detection and Protection
USB Connection Detection and Protection
Beam detection and protection
Current and Voltage Detection and Protection
Emergency Stop Switch
Key Lock
Frame Materials:Aluminum Profile
Motors:NEMA 42 Stepper Motors
Mechanical Precision:Y:12.5um，X:12.5um
Pixel Accuracy:Adjustable (Default: 300 pixels per inch, about 0.81um Pixel Accuracy)
Engraving Area:X400mm*Y400mm
Electric Power:72W
Luminous Power: 5,000-5,500mw
Wave Length:445±5nm
Control Mode:PWM
Power Rate:S0-S1,000
Engraving Speed:0-12,000MM/Min
Baud Rate:115200 - 921600 (Default: 115200)
Computer OS:Win XP, Win 7, Win 8, Win 10 (LaserGRBL)Mac and Linux (LightBurn)
Control Softwares:LaserGRBL (free), LightBurn (not free), Wifi App
Input Format:BMP, JPG, PNG, NC, DXF, SVG, etc.
Available Materials of Engraving:Wood, Paperboard, Black Acrylic, Leather, Some Plastic(opaque), Power Coated Metal, etc.
Available Materials of Cutting:Paper Board, KT Board, Felt Cloth, Leather, Thin Plywood, Thin Black Acrylic, etc.
Input Voltage:110V-240V (Compatible)
Power Adapter Output:24V / 3A
Operating Temp.:-20℃-50℃
How to Select from 2W, 5W, 10W ,20W Laser modules?
2W can do excellent engraving on plywood and leather products, can not do cutting.
5W cut up to 8mm thick wood, 5mm acrylic, carve ceramics and stainless steel.
10W with air assist nozzle, cut through 13mm thick wood 30mm acrylics 5mm MDF.
20W with air assist nozzle/air pump, cut through 20mm pine wood 50mm acrylics 5mm MDF.
ADVANTAGES:
Latest Laser Beam Shaping Technology:Algolaser DIY Kit uses the latest 5.5W laser beam shaping technology diode laser, it has an ultra-fine 0.08mm sharp laser focus, with super cutting penetration and precision, can cut up to 8mm thick wood, 5mm acrylic, carve ceramics and stainless steel.
Offline Control:Support mobile APP control, wifi connection, USB connection, offline USE，The machine is compatible with various mature engraving software, such as LaserGRBL, LightBurn, Benbox, GrblController, LiteFire, supports PWM mode engraving, supports Windows Mac system, and engraving file format Support JPG, PNG, DXF, SVG, G-code, NC, BMP, etc.
Upgraded 32-bit Motherboard/Dual-core CPU:Deliver significant speed boost, achieving an impressive 32% higher CPU performance and 50% improved energy efficiency.8MB RAM, 8MB storage memory, and a built-in 32GB SD card
Easy to Upgrade and Expand:The upgraded terminals of the motherboard, as well as modularization design of DIY kit, allows users to extend the existing frame and connect other accessories to achieve more possibilities.
User-friendly Installation:There are few cables need to connect and each one it's just the right length for its position. The assembly takes only 10~25 mintutes with instruction help, even for newbies.
Square Measuring Ruler:X-axis and Y-axis contain precise scale lines, which is convenient for you to measure the size of engraving objects quickly.
